master Banker's Algorithm with solved question + PYQs

there are three common approaches to dealing with deadlock in operating system

1. prevention
2. detection
3. avoidance

The Banker's Algorithm is a resource allocation and deadlock avoidance algorithm that tests whether the system can allocate resources to each process in a safe sequence.

The name “Banker’s Algorithm” comes from a real-world banking scenario that was explained by the famous computer scientist Edsger Dijkstra.

1. A bank has a fixed amount of money (cash).
2. Customers (processes) can request loans (resources).
3. Each customer has a maximum limit (how much loan they might request in total).

The bank wants to ensure that it never gets into a situation where it can't fulfill the needs of any of its customers — even in the worst case.

or

The bank must ensure that it never gives out too much money, or it might be unable to fulfill future requests.because If a customer later needs more money, but the bank has already loaned out most of its cash, it might not be able to help — this is a dangerous or unsafe situation. –––> this is similar to a deadlock.

So The Bank Must Avoid a Dangerous or unsafe Situation and to avoid dangerous situations, the bank only gives a loan if it can still safely meet the possible future needs of all other customers.

The algorithm is called the “Banker’s Algorithm” because it behaves like a cautious banker (a banker never gives out loans without keeping enough cash to support all customers). Similarly, the OS simulates whether it can still fulfill the maximum demands of all other processes before granting a request and only allocates resources if it is safe to do so.This method helps the OS avoid deadlock, and keep the system running smoothly

Now we will understand in detail how Bankers algorithm works in the operating system

1. In an OS, resources refer to things like: CPU time (processor execution time), Memory (RAM), Disk space, Input/Output devices (like printers, scanners), Files or semaphores These are limited in number, and the OS has to allocate them wisely among processes.
2. Before a process begins execution, it tells the OS the maximum number of each type of resource it might need.
   🔸 This is like a customer telling the bank: “The most loan I might ever need is ₹10,000.”
   This information allows the OS to plan ahead and avoid allocating resources that could cause future deadlocks.
3. The OS maintains a list of how many instances of each resource are currently available.
   Example: 5 printers, 3 CPUs, 10 memory blocks free.
   When a process makes a request, the OS first checks if the requested resources are available right now.
4. It then looks at the remaining needs (i.e., how much more each process might request later) by subtracting:
   Maximum need − Currently allocated
   This helps the OS understand the worst-case demands of all processes in the system.
5. Before actually giving the resources, the OS performs a simulation:
   • It temporarily pretends that the resources have been given.
   • Then it checks: Can all processes still finish eventually, one after the other, if needed?
   This is known as the "safety check".
6. If the simulation shows that the system will remain safe then, The OS grants the resource request and The process continues its work.
7. But if the system might go into an unsafe state (possible future deadlock) then , The OS denies the request, even if the resources are currently free.
